SPECIFICATIONS
Brand Name: NoEnName_Null
Installation Method: self-contained
Hign-concerned Chemical: none
Origin: Mainland China
Grade: DIY, Industrial, commercial, Heavy duty
Warranty: 2 years
Engine Displacement: 803cc
Voltage: 12V
Max Cutting Height: 5"
Min Cutting Height: 1.5"
Customized support: OEM, ODM, OBM
Place of Origin: Zhejiang, China
Brand Name: Speedy
Model Number: SPY-48ZTR
Feature: Height Adjustable Handles, Steel Chasis, lawn mower zero turn
Forward Speed: MAX Cutting speed:10 MPH
Power Source: Petrol/Gasoline
Product name: Zero turn lawn mower
Application: grass cutting
Drive Type: Dual hydro static drive
Cutting width: 48"
Engine: Loncin
Displacement: 803cc
Cutting height: 1.5"~5"
blades: 3
Material: 12 Gauge stamped Steel with 7 Gauge reinforced clutch plate
Front Tire Size and Rear Tire Size: 13 x 5,20 x 8 INCH
#detail_decorate_root .magic-0{width:750px}#detail_decorate_root .magic-1{overflow:hidden;width:750px;height:2312px;margin-top:0;margin-bottom:0;margin-left:0;margin-right:0}#detail_decorate_root .magic-2{margin-top:0;margin-left:0;width:750px;height:2312px}#detail_decorate_root .magic-3{width:446px}#detail_decorate_root .magic-4{overflow:hidden;width:446px;height:400px;margin-top:0;margin-bottom:0;margin-left:0;margin-right:0}#detail_decorate_root .magic-5{margin-top:0;margin-left:0;width:446px;height:400px}#detail_decorate_root .magic-6{width:300px;display:flex;flex-direction:column;margin-right:0;margin-left:4px}#detail_decorate_root .magic-7{overflow:hidden;width:750px;height:1135.5px;margin-top:0;margin-bottom:0;margin-left:0;margin-right:0}#detail_decorate_root .magic-8{margin-top:0;margin-left:0;width:750px;height:1135.5px}#detail_decorate_root .magic-9{overflow:hidden;width:750px;height:1567.5px;margin-top:0;margin-bottom:0;margin-left:0;margin-right:0}#detail_decorate_root .magic-10{margin-top:0;margin-left:0;width:750px;height:1567.5px}#detail_decorate_root .magic-11{overflow:hidden;width:750px;height:675px;margin-top:0;margin-bottom:0;margin-left:0;margin-right:0}#detail_decorate_root .magic-12{margin-top:0;margin-left:0;width:750px;height:675px}#detail_decorate_root .magic-13{overflow:hidden;width:750px;height:856.3291139240507px;margin-top:0;margin-bottom:0;margin-left:0;margin-right:0}#detail_decorate_root .magic-14{margin-top:0;margin-left:0;width:750.0000000000001px;height:856.3291139240507px}#detail_decorate_root .magic-15{width:750px;border-collapse:collapse}#detail_decorate_root .magic-16{min-height:18px;padding:5px 10px;width:51px;min-height:18px;box-sizing:content-box}#detail_decorate_root .magic-17{font-size:12px}#detail_decorate_root .magic-18{min-height:18px;padding:5px 10px;width:46px;box-sizing:content-box}#detail_decorate_root .magic-19{min-height:18px;padding:5px 10px;width:63px;box-sizing:content-box}#detail_decorate_root .magic-20{min-height:18px;padding:5px 10px;width:52px;box-sizing:content-box}#detail_decorate_root .magic-21{min-height:18px;padding:5px 10px;width:53px;min-height:18px;box-sizing:content-box}#detail_decorate_root .magic-22{min-height:18px;padding:5px 10px;width:70px;min-height:18px;box-sizing:content-box}#detail_decorate_root .magic-23{min-height:18px;padding:5px 10px;width:47px;min-height:18px;box-sizing:content-box}#detail_decorate_root .magic-24{min-height:18px;padding:5px 10px;width:62px;box-sizing:content-box}#detail_decorate_root .magic-25{min-height:18px;padding:5px 10px;width:49px;box-sizing:content-box}#detail_decorate_root .magic-26{min-height:18px;padding:5px 10px;width:45px;min-height:18px;box-sizing:content-box}#detail_decorate_root .magic-27{margin-bottom:10px;line-height:0}#detail_decorate_root .magic-28{margin-bottom:0}#detail_decorate_root .magic-29{position:relative;width:100%}
Zero Turn Riding Mower
Item No.SPY-48ZTR
I.Heavy duty stamped deck
II.Loncin 803cc commercial duty engine
III.Bonus items:roll bar, seat belt,arm rests, and cup holders.
IV.48″ width cut
V.Quick adjust floating deck,1.5″ to 5″in 0.5″ increanments
VI.Soft start clutch and spindle brakes
VII.20*8.in rear tires 13*5 in front tires
VIII.Mulching kits available
I.Heavy duty stamped deck
II.Loncin 803cc commercial duty engine
III.Bonus items:roll bar, seat belt,arm rests, and cup holders.
IV.48″ width cut
V.Quick adjust floating deck,1.5″ to 5″in 0.5″ increanments
VI.Soft start clutch and spindle brakes
VII.20*8.in rear tires 13*5 in front tires
VIII.Mulching kits available
|
Model
|
Engine Output Speed (r/min)
|
Gearbox Input Wheel
(mm) |
Gearbox Internal Gear Reduction Ratio
|
Total Deceleration Ratio
|
Gearbox Max Torque
(N.m) |
Hydro Input Speed
(r/min) |
Hydro Output Wheel (Φ)
|
Hydro Max Torque
(N.m) |
Hydro Output Shaft
(Φ) |
|
SPY-48ZTR
|
3600
|
115
|
1:5
|
1:115
|
517.5
|
2260
|
50
|
45
|
19
|
|
SPY-50ZTR
|
3600
|
115
|
1:5
|
1:115
|
517.5
|
2260
|
50
|
45
|
19
|
|
SPY-62ZTR
|
3600
|
150
|
1:5
|
1:125
|
562.5
|
2800
|
60
|
45
|
19
|
